Genuine Kenwood Chef Major Drive Belt KW197944 / 197944 | A701A, KM200 & More

Description

Genuine Kenwood food mixer / food processor drive belt KW197944 (also 197944 / 197920). Toothed motor-to-gearbox belt, approx. 30.5 × 9.03 × 97.1 mm, for Kenwood Chef and Major machines including A701A, A901, KM200 and KM800.

Also known as / replaces / compatible part numbers

• KW197944
• 197944
• 197920

What it does / when to replace

The drive belt transfers power from the motor pulley to the gearbox. Fit a replacement if the attachments stop turning, the belt is cracked or glazed, or the belt keeps riding off the pulleys.

• Motor runs but attachments do not turn
• Cracked, stretched or glazed belt
• Belt repeatedly coming off the pulleys

What’s in the pack

• 1 × genuine Kenwood toothed drive belt

Compatible models

A701, A701A, A707, A707A, A901, A901A, KM200, KM201, KM210, KM220, KM230, KM250, KM290, KM300, KM310, KM315, KM316, KM330, KM331, KM335, KM336, KM340, KM346, KM353, KM400, KM410, KM416, KM417, KM440, KM460, KM600, KM610, KM615, KM630, KM631, KM635, KM636, KM640, KM646, KM800, KM810, KM816, KM840, KMC550, KMC560, KMC570, KMM700, KMM705, KMM710, KMM750, KMM760, PM500, PM900 & Many More

Fitment & care notes

• Isolate from the mains and remove the top cover to access the pulleys. Seat the belt fully on both pulleys and refit any pulley washer.

FAQs

Is this a genuine Kenwood belt?
Yes. This is genuine Kenwood part KW197944 (also 197944 / 197920).

What size is KW197944?
Approximately 30.5 × 9.03 × 97.1 mm toothed belt.

Will it fit a Kenwood Chef A701A or KM200?
Yes – A701A, KM200 and many other Chef/Major models are compatible. Match the number on your old belt.

If you are unsure if this is the correct part, message us with your model or the number on the old part and we will advise.
