Genuine John Lewis Tumble Dryer Water Condensation Pump CMP766518 | Askoll M318 / 1258349214

Description

Genuine John Lewis tumble dryer water condensation pump CMP766518 (Askoll M318 / Hanyu type). OEM-style condensate pump, 240 V AC / 10 W, with two 6.3 mm blade terminals, used to empty water from the condenser sump.

Also known as / replaces / compatible part numbers

• CMP766518
• Askoll M318
• RR0848
• RR084801
• RR0623
• 40005021
• 1258349214
• 125834921
• 8581258349217
• 1258349206

What it does / when to replace

This condensation pump empties water collected by the condenser into the tank or drain. Fit a replacement if the dryer leaves water in the base, the tank does not fill, or the pump runs noisily or not at all.

• Water left in the base or machine not emptying condensate
• Empty-tank light on while water remains in the sump
• Noisy or silent pump during the drying cycle

What’s in the pack

• 1 × genuine John Lewis tumble dryer condensation pump CMP766518

Compatible models

JLTDC05, JLTDC06, JLDTCO1, JLTDC07, JLTDC10, JLTDC09, JLTDC11, JLTDC03, JLTDC12, JLTDH14, JLTDH15, JLTDH17, JLTDH16, JLTDH19, JLTDH18, JLTDH20, JLTDH21, JLTDH23, JLTDH22, JLTDH24 & Many More

Fitment & care notes

• Unplug the dryer before fitting. Match the pump body, mounting and the two 6.3 mm blade terminals to the old unit.
• Rated 240 V AC, 10 W (Askoll M318 / Hanyu type).
• Clear lint from the pump sump and tank hose when replacing.

FAQs

What is CMP766518?
It is a genuine tumble dryer condensation (condensate) pump, Askoll M318 / Hanyu type, 240 V AC, 10 W, with two 6.3 mm blade terminals.

Which part numbers does it replace?
It is listed as CMP766518 and compares to Askoll M318 / RR0848 / RR084801 / RR0623, Candy 40005021, and Electrolux-group numbers including 1258349214, 125834921, 8581258349217 and 1258349206.

What are the electrical ratings?
240 V AC, 10 W, with 2 × 6.3 mm blade terminals.

Will one pump fit AEG, Electrolux, Zanussi, Candy and John Lewis?
The same CMP766518 pump family is used across those brands. Match your model list and the number on the old pump.

If you are unsure if this is the correct part, message us with your model or the number on the old part and we will advise.
