Genuine Whirlpool Sharp Microwave Magnetron 2M167B-M16 481913158019 6MT744IX

Description

Genuine Whirlpool / Sharp microwave magnetron 2M167B-M16 (481913158019). This OEM magnetron is the microwave heating tube for selected Whirlpool and Sharp microwave ovens, including models such as 6MT744IX and the AKB / AVM / MICD / MCCD series listed below. Typical max RF output class about 900 W; body about 130 mm high × 95 mm wide.

Also known as / replaces / compatible part numbers

• 2M167B-M16
• 481913158019

What it does / when to replace

The magnetron generates the microwave energy that heats food. Typical failure signs are a running turntable and light but no heat, unusual buzzing or burning smell from the cavity area, or a blown HT fuse after magnetron short.

Compatible models

Whirlpool: AKB144, AKB143, AKB158, AKB165, AVM749, AVM754, AVM949, AVM954, MICD1820, MCCD1820. Sharp / Whirlpool related: 6MT744IX

Fitment & care

Magnetron and high-voltage capacitor work can kill – fit only by a technically competent person with the appliance unplugged and the HT capacitor safely discharged. Match mounting holes, antenna orientation and connector type to the original 2M167B-M16.

If you are unsure if this is the correct part, message us with your model or the number on the old part and we will advise.
