Genuine DeLonghi ESAM Coffee Machine 06 Series Thermoblock Boiler 1200W 230V 5513227881
£68.99 inc VAT
- Description
- Delivery Information
- Additional information
Description
Genuine DeLonghi ESAM coffee machine 06-series thermoblock boiler, 1200W 230V. Dual-circuit thermoblock heater with 6 mm pipe connection (OEM 5513227881) for Magnifica and related ESAM automatics marked Ø6 / 06 series.
Also known as / replaces / compatible part numbers
- 5513227881
- 06 series
- Ø6
What it does / when to replace
The thermoblock heats water for brewing and steam on automatic ESAM bean-to-cup machines.
- No heat or lukewarm coffee
- Machine errors related to heating
- Open heating element or failed thermoblock
What’s in the pack
1 x 06-series thermoblock boiler assembly.
Compatible models
ESAM3000.B, ESAM3200.S, ESAM3350, ESAM3400.S, ESAM3500.S, ESAM3600, ESAM3650, ESAM4000.B, ESAM4200.S, ESAM4300, ESAM4500, ESAM2000, ESAM2200.S, ESAM2500.B, ESAM2600, ESAM3100.SB, ESAM3300, ESAM3300.S, ESAM4400, ESAM4400.S, ESAM4500.B
Fitment & care notes
Check the stamp on your existing boiler: Ø6 or no diameter stamp uses this 06 / 5513227881 thermoblock; Ø5 needs a different block. Isolate from the mains and relieve residual pressure before disconnecting pipes and sensors. Test the thermal fuse before condemning the whole block.
FAQs
Q: How do I know I need the 06 series block?
A: Look for a Ø6 stamp (or no diameter stamp) by the centre pipe on the old thermoblock. Ø5 machines need a different part.
Q: What wattage is it?
A: 1200W at 230V.
Q: Which OEM number?
A: DeLonghi 5513227881 for the 06 / Ø6 thermoblock.
If you are unsure if this is the correct part, message us with your model or the number on the old part and we will advise.
We strive to dispatch all orders promptly. If an item is unavailable, we will notify you by email. You may cancel delayed orders at any time before dispatch for a full refund.
Delivery Services
- Standard UK Delivery: 2–5 working days.
- Next Day Delivery: Available for in-stock items ordered before the cut-off time on working days. Orders placed after the cut-off, on weekends, or bank holidays will be processed the next working day.
Additional information
| Compatible Brand | For De'Longhi |
|---|---|
| Type | Bean to cup |
| Power | 1200 W |
| Brand | De'Longhi |
